High temperature, high pressure, oil resistant rubber bushing core holder rubber sleeve size can be customized
Description: The core holder is an instrument used to hold and protect the rock sample
and seal the cylinder or end face (usually the end face leaving the fluid inlet and outlet)
in the laboratory to determine the seepage characteristics of the rock sample or to conduct the displacement test.
Simulates the pressure and temperature of deep reservoirs,
and can perform oil-water displacement experiments and core permeability
measurements on cores under simulated formation conditions
Advantages of fluororubber core holder sleeve:
High pressure resistance 700Bar,
wide temperature range, temperature resistance up to 230 degrees Celsius,
Resistant to media: carbon dioxide, oil, acid and alkali, corrosion resistance.
Our company can provide different types of fluorine rubber as the rubber cuff of the core holder,
including FKM A, FKM B, FKM GF, FFKM, etc. Please contact us for detailed physical performance participation.
Application:
Rubber fittings on petroleum, geological and metallurgical scientific research equipment
and rubber sleeves on core holders.
Processing method: Compression set or extrusion
Size:Can be customized according to drawings.
Color: Black brown or other customized colors.
Material data sheet:
| The composition of the core holder |
| Core holder shell | Core holder end | Rubber sleeve
and sealing device |
General use
stainless steel | General use
stainless steel | sodium butadiene rubber,
fluorine rubber,
silicone rubber |
Type 304, 316,
316L alloy | Type 304, 316,
317L alloy | |
Picture shows:
